The microscopy facility of the Campus Saint Germain des Prés (CSGP) offers access to photonic microscopy techniques (widefield, confocal, Airyscan, slide scanner) along with tools for image analysis and storage solutions. The facility is run by an operations manager and a scientific manager. The main decisions are made with the committee, representing each CSGP research unit and which is consulted approximately once a month. Located on the 4th floor of the UFR des Sciences Fondamentales et Biomédicales, the facility is open to the researchers, engineers, technicians and students of the building and to external teams/private companies. The ambition of the facility is to expand according to the users’ needs.
News
Team
Equipements
ZEISS LSM880 Fast Airyscan
– Room H423B
- High-resolution confocal
- 3D acquisition, time lapse, tiles, multi-positions, FRAP, spectral deconvolution
- Fixed/living samples
- Temperature and CO2 control
- Definite focus 2
- Software ZEN Black 2.3
| Lasers | Objectives | Detection |
| 405 nm 445 nm 488 nm 514 nm 561 nm 594 nm 633 nm |
10x/0.45 Dry WD : 2 mm 20x/0.8 Dry WD : 0.55 mm 40x/1.2 Water Autocorr. WD : 0.28 mm 63x/1.4 Oil DIC WD : 0.19 mm |
2 PMTs 1 spectral PMT GaAsP 1 Airyscan detector GaAsP 1 Trans-PMT |
ZEISS LSM710 Confocal
– Room H423A
- 3D acquisition, time lapse, tiles, multi-positions, FRAP, spectral deconvolution
- Fixed/living samples
- Software ZEN Black 2.1
| Lasers | Objectives | Detection |
| 405 nm 458 nm 488 nm 514 nm 561 nm 633 nm |
10x/0.45 Dry WD : 2 mm 20x/0.8 Dry WD : 0.55 mm 40x/1 Water DIC WD : 2.5 mm 63x/1.4 Oil WD : 0.19 mm 63x/1.2 Water WD : 0.28 mm |
2 PMTs 1 spectral PMT 1 Trans-PMT |
ZEISS LSM510 Confocal
– Room H423A
- 3D acquisition, time lapse
- Fixed samples
- Software ZEN 2009
| Lasers | Objectives | Detection |
| 458 nm 477 nm 488 nm 514 nm 543 nm 633 nm |
2.5x/0.12 Dry WD : 6.3 mm 10x/0.3 Dry WD : 5.2 mm 20x/0.5 Dry WD : 2 mm 40x/1.3 Oil DIC WD : 0.2 mm 63x/1.4 Oil DIC WD : 0.19 mm |
2 PMTs 1 Trans-PMT |
ZEISS AxioScan.Z1 Slide scanner
– Room H423A
- 100 slides magazine, 3D acquisitions
- Fixed samples
- Brightfield, Fluorescence, Polarization
- Lightsource : Colibri 7 – LED System
- Camera 1 : Hamamatsu ORCA-Flash 4.0 (2048 x 2048, 6.5µm)
- Camera 2 : Hitachi HV F202 (1600 x 1200, 4.4µm )
- Graphic tab
- Software : ZEN 3.1
| LEDs | Objectives | Emission Filterwheel |
| 385 nm 430 nm 475 nm 511 nm 555 nm 590 nm 630 nm |
10x/0.45 Dry 20x/0.80 Dry 40x/0.95 Dry |
DAPI, Alexa Fluor 488 / 555 / 647 QBP : 425/30 + 514/30 + 592/25 + 709/100 CFP, YFP, mCherry TBP : 467/24 + 555/25 + 687/145 DAPI, FITC, mCherry TBP : 425/30 + 524/50 + 688/145 |
Nikon Eclipse TE-2000E Widefield microscope
– Room H438A
- 3D acquisition, time lapse, tiles, mutli-positions
- Brightfield/Fluorescence
- Fixed/living samples
- Temperature control
- Fluorescent lamp metal halide Nikon Intensilight 130W
- Camera 1 : Photometrics CoolSnap HQ2 (1392 x 1040, 6.45 μm)
- Camera 2 : QImaging Color Retiga 2000R (1600 x 1200, 7.4 μm)
- Software : NIS-Elements AR 3
| Objectives | Fluorescence cubes filters |
| 4x/0.13 Dry WD : 17.2 mm 10x/0.30 Dry WD : 16 mm 20x/0.75 Dry DIC WD : 1 mm 40x/1.30 Oil DIC WD : 0.2 mm 100x/1.45 Oil WD : 0.13 mm |
Dapi (377/50 D409 447/60) GFP (480/30 D505 535/40) TRITC (540/25 D565 605/55) Cy5 (628/40 D660 692/40) CFP (436/20 D455 480/10) YFP (500/20 D515 535/30) |
ZEISS Axioscope.A1 Widefield microscope
– Room H438A
- Brightfield/Fluorescence
- Fixed samples
- Fluorescent lamp metal halide Zeiss HXP 120 C
- Camera 1 : Progres MF-USB Jenoptik (1360 x 1024, 6.45 μm)
- Software : ProgRes Capture Pro
| Objectives | Fluorescence cubes filters |
| 5x/0.16 Dry WD : 18.5 mm 10x/0.30 Dry WD : 5.2 mm 100x/1.4 Oil WD : 0.17 mm (sur demande 20x, 40x) |
Dapi (365 D395 445/50) FITC (475/40 D500 530/50) TRITC (545/25 D570 605/70) Cy5 (640/30 D660 690/50) |
Analysis Workstation 1
– Room H420B
- AutoQuant X 3.1.3 Deconvolution software
- Ilastik 1.4.0
- QuPath v0.5.0
Analysis Workstation 2
– Room H420B
- Imaris 10 (Cell, Imaris XT, Coloc, Filament Tracer, Vantage, Batch)
- ZEN Blue lite
- ZEN Black lite (with Airscan processing module)
- NIS Elements AR Off-line
- ImageJ/Fiji
Laboratory fume cupboard – Sodatec
– Room H420A
- 3 micropipets Gilson (P20, P200, P2000) + pipet tips
- Dirt containers (sharp objetcts/paraformaldehyde)
- Precision Balance
- Digital Refractometer (DR301-95)
STORAGE SOLUTIONS AND POLICY
The images acquired on our systems are first stored on the acquisition computer. After each session on the systems, the user can transfer the files from the computer to our server (100 To). The images are stored on our computers for 6 months and for 3 years on our servers. After the delay, they are automatically deleted.
PRESTATIONS
The microscopy facility provides trainings on all the equipments mentioned above, under request. The autonomous users can ask to be assisted by a member of the facility if needed. We also provide our expertise and advices to guide our users in their experiments regarding sample preparation, if possible, imaging and image analysis.
PRICES
Prices 2024 (without engineer assistance)
| Equipements | Tarifs d'utilisation interne académique CSG (HT) | Tarifs d'utilisation externe académique Paris Cité (HT) | Tarifs d'utilisation externe académique (HT) | Tarifs d'utilisation privée (HT) |
| Sorbonne (Hotte Laboratoire) | Gratuit | Gratuit | Gratuit | Gratuit |
| Microscope Zeiss Primo Star | Gratuit | Gratuit | Gratuit | Gratuit |
| Slide Scanner Zeiss AxioScan.Z1 | 6 € / Heure Scans longs nuit(17h-9h) : 40€ |
8 € / Heure Scans longs nuit(17h-9h) : 55€ |
10 € / Heure Scans longs nuit(17h-9h) : 80€ |
21 € / Heure Scans longs nuit(17h-9h) : 160€ |
| Microscope WF 1 - NIKON Eclipse-TE2000E | 9 € / Heure | 9 € / Heure | 12 € / Heure | 20 € / Heure |
| Microscope WF 2 - ZEISS Axioscope A1 | Gratuit | Gratuit | Gratuit | Gratuit |
| Microscope Confocal 1 - ZEISS LSM 510 | 18 € / Heure | 20 € / Heure | 22 € / Heure | 36 € / Heure |
| Microscope Confocal 2 - ZEISS LSM 710 | 21 € / Heure | 23 € / Heure | 26 € / Heure | 42 € / Heure |
| Microscope Confocal 3 - ZEISS LSM 880 | 26 € / Heure | 32 € / Heure | 41 € / Heure | 73 € / Heure |
| Analysis WS 1 - Déconvolution | Gratuit | Gratuit | 5 € / Heure | 10 € / Heure |
| Analysis WS 2 – Reconstruction 3D | Gratuit | Gratuit | 7 € / Heure | 15 € / Heure |
Contact / Access / Documention
Any question ? Please contact this address in order to have a better answser : scm@u-paris-sciences.fr / 01 76 53 10 77
Find the Microscopy Platform on the 4th floor of the Saints-Pères building and all the access details by following this link.
Charte SCM (PDF)
Remerciements UAR (PDF)
